FSA
Orbit C-33
Orbit C-33
Regular price
$104.99 CAD
Regular price
Sale price
$104.99 CAD
Unit price
/
per
Couldn't load pickup availability
- 1-1/8''/1-1/4'', 45°/45° ACB
- Compatible with carbon or alloy head tubes
- For tapered 47 mm/52 mm OD head tube
- For 1-1/8'' to 1-1/4'' tapered fork
- Carbon-fiber top cover
- Upper: 1-1/8'' angular contact bearing (yellow seal)
- Lower: 1-1/4'' angular contact bearing (black seal)
- Stack height: 15.6 mm + 1 mm = 16.6 mm
- Weight: 69 g
Attributes
| Bearing Grade | ACB Sealed |
| Crown Race Diameter | 33mm |
| Headset Position | Complete |
| Headset Type | Integrated |
| Headset Weight | 69g |
| Lower Cup | 47mm |
| Misc | 45°/45° ACB (black seal) |
| Primary Color | Carbon |
| S.H.I.S. | IS42/28.6 | IS47/33 |
| SHIS Lower | IS47/33 |
| SHIS Upper | IS42/28.6 |
| Stack Height | 16.6 |
| Steerer Tube | 1-1/8''-1-1/4'' |
| Upper Cup | 42mm |
